Zenmuse X5S
The Zenmuse X5S supports 5.2K 30fps video recording in CinemaDNG format and up to
20.80MP still photo capture. It has a camera system with an M4/3 interchangeable lens. As with
other DJI 3-axis gimbal systems, the Zenmuse X5S can be mounted onto a DJI aircraft and can
stream live HD video wirelessly to the DJI GO
TM
4 app.
1. DJI Gimbal Connector 2.0
2. Pan Motor
3. Tilt Motor
4. DJI MFT 15mm F/1.7-16 ASPH Lens*
5. Balancing Ring (BR-Φ46-10)*
6. Lens Hood*
In the Box
* The Zenmuse X5S Lens Kit includes the original lens, balancing ring, lens cap, rear lens cap
and lens hood. Accessories for other supported lenses can be purchased separately.
Gimbal and Camera ×1 Camera Body Cap ×1 Lens Rear Cap*×1
1
2
3
4
5
7
8
9
11
6
10
7. Lens Cap*
8. Lens Mount Index
9. Lens Release Button
10. Lens Mount
11. Roll Motor
