djpower FLAME MACHINE HF-210 - Page 13

- 12 -
5.4.6. DMX CONTROL
Channel
Function
Value
Setting
（CH1）
Angle
6~249
from -105° to 105°, 128, 0-5, and 250-255 all is straight upward.
（CH2）
Speed
0
Max speed
1~254
Speed increases
255
Max speed
（CH3）
Ignition
0~253
Ignition OFF
254~255
Ignition ON
（CH4）
Opening time
0
Permanent fire
1~254
In steps of 10ms, to 2540ms
Opening time= DMX Value * 10ms
255
Permanent fire
（CH5）
Program Sequence
0~2
No preset sequence
3~255
Preset sequence.
Sequence No.= DMX value÷3（round numbers）
（CH6）
Mode
0~49
Pressure Relief Mode (Emergency Stop)
50~200
Compression Mode
201~255
Pressure Relief Mode (Emergency Stop)
5.4.6.1. About Channel
1.The first channel controls the firing angle. It defines to which angle the nozzle of Wave flame machine move to. The angle can be chosen
anywhere between -105° to +105° (DMX value 0 to 255).
2. The DMX value for angle of 0° is 127.5 (round up 128). Use this value, following formula can be used to calculate all other angles ∠ in
degree. Please always note the prefix of the angle.
DMX Value = 127.5 + (∠*1.2145)
（CH1）： Angle
81
Step 4>12
LONG flame Step sequence
L -> R
5.08s
243-245
82
Step 12>4
LONG flame Step sequence
R -> L
5.08s
246-248
83
Step 5>11
LONG flame Step sequence
L -> R
3.81s
249-251
84
Step 11>5
LONG flame Step sequence
R -> L
3.81s
252-254
85
Step 7>9
LONG flame Step sequence
L -> R
1.27s
255
Angle No.
Angle
DMX Value
1
-105°
6
2
-90°
24
3
-75°
42
4
-60°
60
5
-45°
79
7
-15°
97
