djpower FLAME MACHINE HF-210 - Flight Case Dimensions

- 4 -
2.5. Flight Case Dimensions
3. TECHNICAL SPECIFICATIONS
Voltage
AC 110-120V,50/60 Hz
AC 220-240 V, 50/60 Hz
Breaker
5 A, 250 V
Current limiting
insurance type
Breaker
Power
300 W
Tank Capacity
10 L
Horizontal placement
√
Tilt
×
Side placement
×
Up-side-Down
×
Hang
×
Body Control
LCD control panel
Wireless Control
×
Wire Control
√
Maximum Output Height
Appr. 8-10 meters(no wind condition)
Effect Angles
210°(±150°)
Fluid Consumption Rate
Appr. 0.48 min/L
Consumable
Isopropyl alcohol, Bio-Ethanol, Isopar-G( It is a must to add 10-
20ML castor oil to every 10L of fuel to protect the pump from being damaged)
Machine Net Weight
28 kg
Flightcase Net Weight
8 kg
Gross Weight
40 kg
Machine Dimensions
588 × 362 × 367 mm
Flightcase Dimensions
645 × 405 × 504 mm
Packing Dimensions
720 × 480 × 570 mm
