DK2 BCR690E - Full Parts List

18 | BCR690E man. v.210310
ENGLISH
No Description Qty
1 bike hook 2
2 front wheel 2
3 tube cap 2
4 hexagon round head screw M5*25 half thread 2
5 hook tube profile 2
6 washer M5*10*1 2
7 M5 lock nut 2
8 bike tube profile 2
9 washer M8*20*1.5 4
10 cross hexagon head screw M8*25 4
11 plastic cover for hook tube 4
12 hexagon round head screw M6*40 2
13 washer M6*12*1 4
14 hook round tube cap 2
15 flex round pin for hook 4
16 lock nut M6 2
17 hexagon screw M12*85 half thread 1
18 quick fixing pin 1
19 washer 12*24*2.5 6
20 hexagon screw M12*80 half thread 2
21 hitch basic plate 1
22 hitch pin M16*95 1
23 flex washer M16 1
24 washer M16*30*2 1
25 2 inch hitch receiver 1
26 B pin 4*85 1
27 2 inch hitch receiver cap 2
28 lock nut M12 3
29 left plastic sheet for hitch plate 1
30 right plastic sheet for hitch plate 1
31 spring 1
32 tube inside pin 12*17*50 1
33 metal matt 1
34 tilting handle 1
35 tube connector plate with nut 2
36 tube connector plate 2
37 head hexagon screw M8*30 8
38 head hexagon screw M6*12 2
39 rear wheel holder 2
40 tube profile cap 4
41 tilting tube 1
42 hook round tube ending cap 2
ASSEMBLY
FULL PARTS LIST
