DRAIN INSTALLATION DRAIN PUMP INSTALLATION
ROOF INSTALLATION SPRAYER ADJUSTMENT
ARCH SECTION SETUP ARCH SECTION SETUP
1 2
Retrieve arch sections from labeled frame bags. Swing joints and pin
in place. Be sure to orient pins toward interior of shelter to prevent
pin extraction.
Retrieve ridge support bars from labeled frame bags. Insert into
socket with label A facing up. Pin in place. Connect arms along
frame making sure angle points to center. Label B should align with
each other.
To Next Page
