LABEL UP!
BOLT SHOULD FACE DOWN
DRAIN INSTALLATION DRAIN PUMP INSTALLATION
SPRAYER ADJUSTMENT
CENTER FRAME SETUP SHOULDER SUPPORT BARS
3 4
Position center frame section in desired location. Lift and connect
arch sections in a clockwise or counterclockwise rotation. Pin in
place with cable underneath frame.
Connect shoulder support bars. Orient support bar so that the Label
D faces up. Insert pin down into socket to secure.
To Next Page
