DMC HI-CAP 40 - Trash Pan Parts

15
Parts ListHi-Cap 40 Grain Cleaner
Trash Pan
Reference Part Quantity
Numbe
r
Numbe
r
Description Needed
1 202D0004 Drum side panel support post 2
2 202D0005
S
ide panel
f
rame bracket 2
3 202D0008 Discharge auger 1
4 202D0009 Belt shield support bracket 1
5 202D0010 Lower belt shield 1
6 202D0011 Upper belt shield 1
7
202D0012
D
rum s
id
e pane
l
1
8 202D0014 End panel - Front 1
9
202D0017
E
n
d
pane
l
-
R
ea
r
1
10 202D0019 Trash pan side panel - Right 1
11
202D0020
T
ras
h
pan s
id
e pane
l
-
L
e
ft
1
12 205B0057 Idler spacer bushing, 3
/
4" long 1
13 PT0132 Wood Bearing, 7
/
8"
(
complete
)
2
14 PT0228 Wood Bearing, 7
/
8" 1
15 PT0426 3 Hole stamped
f
langette 2
16 PT0516
A
-112, V-Bel
t
1
17 PT0660 Pulley, 7
/
8" x 8", A section 1
18 PT0711 Flanged idler pulley, 1
/
2" x 3-1
/
4" 1
19 1FH0763 Hex nut, 1
/
4" 4
20
1FH0764
H
ex nu
t
,
5/16"
6
21 1FH0767 Hex nut, 1
/
2" 1
22
1FH0970
H
ex
fl
ange
l
oc
k
nu
t
,
1/4"
35
23 2FH0512
S
ocket head set screw, 5
/
16" x 5
/
16" 1
24
2FH0631
C
arr
i
age
b
o
lt
,
1/4"
x
3/4"
2
25 2FH0645
C
arriage bolt, 5
/
16" x 3
/
4" 6
26 2FH0803 Hex bolt, 1
/
4" x 3
/
4" 6
27 2FH0911 Hex bolt, 1
/
2" x 3" 1
28 2FH0979 Hex
f
lange whiz lock screw, 1
/
4" x 5
/
8" 31
29 3FH0770
C
otter hair pin, 1
/
8" x 2-3
/
8" 2
30 3FH0789 Lock washer, 1
/
4" 4
31 3FH0790 Lock washer, 5
/
16" 6
32 3FH0793 Lock washer, 1
/
2" 1
33
3FH0834
M
ac
hi
nery
b
us
hi
ng,
7/8"
ID
x
1
-
3/8"
OD
x
10
GA
1
34 3FH0863 Flat washer, 1
/
4" 2
35
3FH0867
Fl
a
t
was
h
er,
1/2"
2
36 3FH0932
S
pring pin, 3
/
16" x 1-1
/
2" 1
37
3FH0992
W
oo
d
ru
ff
k
ey,
3/16"
x
1"
1
