DMG DEUM.M15SER - Page 22

DEUM.M15SER - DEUM.M15CAN
22
ALIM
12/24V
DC
DEUM.M15CAN
X04/DU/G3 X03/CU/G2/SS X02/BU/G1/SI X01/AU/G0/PP
INPUT 12/48V AC/DC
ARROW
INPUT
12/48V
INPUT 12/48V AC/DC
UP
DOWN
COM ARR
TRG 1
TRG 2
START
SOUND
INPUT
12/48V
X15/S1
COM X14-15
EME
+
-
+
ALIM ALIM
ADV PRG
ALIM
ALIM
CANH
CANL
+
-
CAN BUS
En = error code
An = offset value
Bn = input type
Cn = arrow mode
Dn = offset mode
Fn = energy saving
Gn = First visualization
Hn = Input Grouping
n = see manual
DISPLAY LEGEND
3Wire Serial Output
ALIM
ALIM
CABIN LINE
HALL LINE
+
-
Display TFT DMG CAN
Display TFT DMG CAN
Display TFT DMG CAN
CABINA / CAR
+ALIM -ALIM
ALIM +
ALIM -
Collegamento aggiuntivo in caso di assorbimento > 2A (circa 16 display di piano)
Additional wiring with absorption > 2A (about 16 floor position indicator)
Connexion supplémentaire en cas d'absorption > 2A (environ 16 afficheur paliers)
Zusatzverdrahtung mit Absorption > 2A (ungefähr 16 Bodenanzeigen)
Cableado adicional con absorción > 2A (aproximadamente 16 pantallas del piso)
