DMG DEUM.M15SER - Position and Signal Input Allocation

DEUM.M15SER - DEUM.M15CAN
36
PRG
PRG PRG
6
PRG
6
PRG
2X
6
6X
3.4.7 - Ripartizione ingressi di posizione e segnalazioni
Allocation of Position inputs and signals • Subdivision des entrées de position et des
signaux • Zuweisung der Positionseingänge und Anzeigen • Subdivisión de entradas de
posición y señales.
PRG
H0 H1 H2
ADV
Default ->
H0
H1
H2
Ingressi di posizione
Position inputs
Entrées de position
Positionseingänge
Entradas de posición
Segnalazioni
Signals
Signaux
Anzeigen
señalizaciónes
X01 ÷ X15 -
X01 ÷ X8 S1 ÷ S7
X01 ÷ X5 S1 ÷ S10
ALIM
12/24V
DC
DEUM.M15___
COM X09-13
X08/GD/S8
COM X01-08
X07/GU/G6/S9 X06/FU/G5/S10 X05/EU/G4 X04/DU/G3 X03/CU/G2/SS X02/BU/G1/SI X01/AU/G0/PP
INPUT 12/48V AC/DC
ARROW
INPUT
12/48V
INPUT 12/48V AC/DC
UP
DOWN
COM ARR
TRG 1
TRG 2
START
SOUND
INPUT
12/48V
X10/BD/S6
X11/CD/S5
X12/DD/S4
X13/ED/S3
X14/FD/S2
X15/S1
COM X14-15
X09/AD/S7
EME
+
-
+
ALIM ALIM
ADV PRG
En = error code
An = offset value
Bn = input type
Cn = arrow mode
Dn = offset mode
Fn = energy saving
Gn = First visualization
Hn = Input Grouping
n = see manual
DISPLAY LEGEND
