Field Description Navigation Values (group of 12)
MTPX Line
MULTIPLEX
Communication Line
▲▼ (Change
page)
ENTER (Reset)
ESC (Exit)
Error: Communications error number
FER: Frame Error Rate
Date and hour of last reset
ELGO model: ELGO’s Diagnostic
PLAYBOARD IN-OUT table description parameters
Input Description
SE0 Safety chain Start
SE1 Safety chain pit safety contacts
SE2 Safety chain top of car inspection Box/Stop
SE3 Safety chain final limit switch, safety gear, speed governor
SE4 Safety chain hall doors preliminary contacts
SE5 Safety chain hall doors inerlocks
SE6 Safety chain car doors contacts and pre trigger device (81-21)
CCO
CCOB
power contactors control
CISO Monitor ISO relay
TISO Safety Module SM1 control
LE Emergency Light (car light power supply)
BFR door close button
PCA Elevator car priority function
POM Fire-fighters operations (Hall key switch)
CPOM Fire-fighters operations (Car key switch)
SUR Overload control
COM Full load control
HS out of service function
ZP door zone signal
RPH Phase sequence control
REV
REV1
REV2
Inspection function (machine room)
Inspection function (Top of Car)
Inspection function (PIT)
REM
REM1
REM2
Inspection up (machine room)
Inspection up (Top of Car)
Inspection up (PIT)
RED
RED1
RED2
Inspection down (machine room)
Inspection down (Top of Car)
Inspection down (PIT)
TH1
TH2
Motor (Oil) temperature sensor control
