Input Description
IEME Emergency (power supply failure)
PME PME selector (emergency evacuation)
AGH
AGB
Top deceleration switch
Bottom deceleration switch
FAS
FAI
Position Sensors (no encoder positioning system)
E511 Optional input for Shaft Access
BYPL
BYPC
Door’s safety Bypass selector
BRA Door open button (entrance A)
CEA Photocell entrance A
FOA Door open limit switch entrance A
FFA Door close limit switch entrance A
BRB Door open button (entrance B)
CEB Photocell entrance B
FOB Door open limit switch entrance B
FFB Fine corsa chiusura (Porta B)
BR1 Brake 1 monitor switch
BR2 Brake 2 monitor switch
IN_A
IN_D
Monitor UCM circuit
Output Description
VHS Output - out of order illumination
RMV Output – intermediate speed command
BRK Output - Brake command
MTR Output - Motor command
YBRK Output - Brake command (VVVF)
ISO Output - Re-levelling command
RGV Output - high speed command
RPV Output - low speed command
RMO Output - up travel command
RDE Output - down travel command
LTMP Output - time limited car light command
CAM Output - retiring ramp command
OEM Output - emergency command
CCF Output - Motor phase short Circuit
J20 Output - programmable (connector J20)
DSA Output - alarms de-activation
