Output Description
511B Output - Norm 511 Buzzer
511L Output - Norm 511 Light
212B Output - Norm 212 Buzzer
FLD Output - down arrows command
FLM Output - up arrows command
GNGD Output - upward gong command
GNGM Output - downward gong command
BIP Output – BIP signalization in the cabin
PWR UCM module power command
ENAB UCM module enabling command
ROA Output - door open command (entrance A)
RFA Output - door close command (entrance A)
ROB Output - door open command (entrance B)
RFB Output - door close command (entrance B)
L-RED Traffic Light signal 81-20/21
L-GREEN Traffic Light signal 81-20/21
BUZZER Buzzer signal for bypass 81-20
VVVF IN-OUT table description parameters
Signal Description
EN Enable digital input (screw terminal EN)
FWD Upward digital input (screw terminal FWD)
REV Downward digital input (screw terminal REV)
X1 High speed digital input (screw terminal X1)
X2 REV speed digital input (screw terminal X2)
X3 Low speed digital input (screw terminal X3)
X4 Ingresso digitale (morsetto X4)
X5 digital input (screw terminal X4)
X6 Ingresso digitale (morsetto X6)
X7 Ingresso digitale (morsetto X7)
X8 Emergency digital input (screw terminal X8)
0,0 V VVVF analog input (terminals 11-12)
Encoder Encoder VVVF input (closed loop)
MAIN VVVF firmware version
Y1 Digital output (terminal Y1)
Y2 Digital output (terminal Y2)
Y3 Digital output (terminal Y3)
