DMG Pitagora 4.0 - Page 28

“Configuration” Menu
----->>>>> ----->>>>>
OR
----->>>>> ----->>>>>
Floor 0 - 12:30:56
< Configuration >
Signal Description
Y4 Digital output (terminal Y4)
Y5A/C Brake command relays (terminal Y5)
30 A/B/C Relè (terminal 30 A/B/C)
ALM Alarm VVVF signalisation
RST Reset VVVF
ACC Acceleration
DEC Deceleration
Fout Output Frequency
Vout Output Voltage
Iout Output current
Imax Maximum output current
Table of Parameters:
Parameter Description Navigation Values
Default
Value
Temporary
operations
Temporary operations mode of the system ◄► (Choice) No; Yes No
Test
To ease checks and installation start-up.
For description, refer to Annex II.
Code ? Password protection to access programming
◄► (Change
characters)
▲▼ (Select
characters)
8 characters
(0 - 9; A - Z;
a - z )
no
password
Table of Parameters
