DMG Pitagora 4.0 - VVVF Menu

“VVVF” Menu
This menu is available only when a FUJI FRENIC LIFT VVVF is connected to a Control Lift Board.
----->>>>> ----->>>>>
OR
----->>>>> ----->>>>>
Floor 0 - 12:30:56
< VVVF >
Parameter Description Navigation Values
Default
Value
Monitor
Encoder
Contains information on:
Encoder features, reading of slowdown heights (R1D
/ R1S), re-levelling (RRIPD / RRIPS) and stop of the
cabin (RLD / RLS) where D indicates down while S
means up; finally it contains info on reading AGB /
AGH and ZP heights.
Note: R1D and R1S heights can be modified pushing
Enter without repeating self learning procedure (to
let the slowing down distance be equal in rise and
descent).
Door Zone Lenght of door zone ZP in mm
NOTE: Please consult the time diagram at the end of this manual, to better understand some parameter meanings.
VVVF Basic menu list Parameters
Cod. Parameter Description Navigation Values Default Value
F03
Maximum
speed
Max speed of the motor
◄►
(Selection)
▲▼
(Change
value)
150-
3600
RPM
1500 RPM
F05
Rated
Voltage
Rated voltage of the motor driven by the
inverter
◄►
(Selection)
▲▼
(Change
value)
160-
500 V
380 V
VVVF Basic menu list Parameters
