DMG Pitagora 4.0 - Page 45

Cod. Parameter Description Navigation Values
Default
Value
F03
Maximum
speed
Max speed of the motor
◄►
(Selection)
▲▼
(Change
value)
150-3600 RPM 1500 RPM
F04
Rated
speed
Rated speed of the motor (Frequency)
◄►
(Selection)
▲▼
(Change
value)
50 Hz
F05
Rated
Voltage
Rated voltage of the motor driven by
the inverter
◄►
(Selection)
▲▼
(Change
value)
160-500 V 380 V
F07 Acc T1
Acceleration ramp (only with FAI/FAS
positioning system)
◄►
(Selection)
▲▼
(Change
value)
0,00-99,9 sec
1,8 sec
(FAI/FAS)
0,01 sec
(Encoder)
F08 Dec T2
Deceleration ramp (only with FAI/FAS
positioning system)
◄►
(Selection)
▲▼
(Change
value)
0,00-99,9 sec
1,8 sec
(FAI/FAS)
0,01 sec
(Encoder)
F09
TRQ
Boost
Torque increase
◄►
(Selection)
▲▼
(Change
value)
0,0-5,0 0,0
F10
Electronic
OL
Overload electrical protection
◄►
(Selection)
▲▼
(Change
value)
1 - 2 2
F11
Overload
Level
Electronic Thermal Overload Protection
for Motor (Value in Ampere equal to the
inverter size)
◄►
(Selection)
▲▼
(Change
value)
1 to 200% of the rated
current
100 % of the
rated current
F12
Overload
time
Thermic time constant
◄►
(Selection)
▲▼
(Change
value)
0.5 – 75.0 min.
5.0 (up to 22
kW)
10.0 (up to
30 kW)
