Controller power supply
Power supply from a commercial stabilized power supplier.
The negative terminal of the power circuits and the battery charger must be connected to the ground.
Internal Clock power supply: Super Capacitor (autonomy of 5 days without power supply).
Encoder Position
Positioning system based on an incremental encoder:
DMG Shaft Encoder or
Motor Encoder (only for VVVF Gearless Motor Lift)
In case of Absolute Encoder Positioning system this connector is not used.
Relevelling Circuit
Circuit to make Door Safety Contact Bypass for:
Pre opening and/or
Re-levelling
