LED DESCRIPTION
MODE
Normal mode Slow Flashing (1 s)
Pre-Commissioning Mode Fast Flashing (0,1 s)
Teach Mode Lights permanently
ERROR
No Error Led OFF
Generic Error Led ON
Emergency Error Flashing
TAPE Magnetic Tape not detected Led ON
eSGC
eSGC Contact close Led ON
eSGC Contact Open Led OFF
OC
OC Contact close Led ON
OC Contact Open Led OFF
SR1
SR1 Contact close Led ON
SR1 Contact Open Led OFF
SR2
SR2 Contact close Led ON
SR2 Contact Open Led OFF
CAN-ERR Status CAN Open Led ON
CAN-RUN Status Can Open Led OFF
Explanation of safety contacts
Reduced Head and/or Reduced PIT Installation
Sufficient Head and Pit clearance
according EN81-20 §5.2.5.7 / § 5.2.5.8
