Reduced Head and/or Reduced PIT Installation
Sufficient Head and Pit clearance
according EN81-20 §5.2.5.7 / § 5.2.5.8
Pre-Triggered Stopping System Offset Up F2) - Lower inspection limit switch
Pre-Triggered Stopping System Offset Down
For manual adjustment of the positions of the indicated is possible from menu <Positioning> Monitor Encoer (see
table below).
Label Page Description
N_LIM_S 7 Upper final limit switch offset (offset over top floor)
N_LIM_D 7 Lower final limit switch offset (offset under bottom floor)
I_LIM_S 6 Upper inspection limit switch (offset under top floor)
I_LIM_D 6 Lower inspection limit switch (offset over bottom floor)
TRIPS 8 Upper Pre-Triggered Stopping System limit (from Upper Reference Position)
TRIPD 8 Lower Pre-Triggered Stopping System limit (from Lower Reference Position)
TRIPS and TRIPD values are used only if ELGO is part of Safety System for Reduced Head and/or Pit (ELGO +
eSGC).
