DMG Pitagora 4.0 - Annex 1 - Multiplex Parameters Setting

Annexs
Annex 1 – Multiplex Parameters Setting
Speed [m/s] Deceleration [mm] Acceleration time [s]
3,8 11000 5,8
3,9 11500 5,9
4,0 12000 6,0
– Example 1 –
Floors in Multiplex Controller A floors Controller B floors
7 7 7
6 6 6
5 5 5
4 4 4
3 3 3
2 2 2
1 1 1
0 0 0
Controller A Controller B
Number of floors 8 8
...
Multiplex configuration
Lift number 1.X 2.X
Floors in Multiplex 8 8
OFFSET 0 0
NOTE : please refer to examples 5 and 6 for the configuration of the button wiring indicated with X
Duplex elevator (example 1)
– Example 2 –
Floors in Multiplex Controller A floors Controller B floors
7 7 5
Duplex “Dog Leg”elevator (example 2/3/4)
