DMG Pitagora 4.0 - Page 80

Floors in Multiplex Controller A floors Controller B floors
6 6 4
5 5 3
4 4 2
3 3 1
2 2 0
1 1
0 0
Controller A Controller B
Number of floors 8 6
...
Multiplex configuration
Lift number 1.X 2.X
Floors in Multiplex 8 8
OFFSET 0 2
NOTE : please refer to examples 5 and 6 for the configuration of the button wiring indicated with X
– Example 3 –
Floors in Multiplex Controller A floors Controller B floors
7 7
6 6
5 5
4 4 4
3 3 3
2 2 2
1 1 1
0 0 0
Controller A Controller B
Number of floors 8 5
...
Multiplex configuration
Lift number 1.X 2.X
Floors in Multiplex 8 8
OFFSET 0 0
