DMG Pitagora 4.0 - Page 81

NOTE : please refer to examples 5 and 6 for the configuration of the button wiring indicated with X
– Example 4 –
Floors in Multiplex Controller A floors Controller B floors
7 5
6 4
5 5 3
4 4 2
3 3 1
2 2 0
1 1
0 0
Controller A Controller B
Number of floors 6 6
...
Multiplex configuration
Lift number 1.X 2.X
Floors in Multiplex 8 8
OFFSET 0 2
NOTE : please refer to examples 5 and 6 for the configuration of the button wiring indicated with X
– Example 5 –
Controller A Push-buttons Controller B
7
7
6
6
5
5
4
4
Shared button wiring (example 5)
