User Manual C-6000i Computerized Jigging Reel
30
As an example of how the power factor works lets say that its value has
been set at 3. Now the reel will use 30% of the power, as set by the
hauling power parameter (see page 24), when the speed is 0 RPM and
100% when the speed is 500 RPM (see
Figure 15). At any other speed the power is linearly interpolated
between these two values. In this case the power used at 250 RPM
would be 65%.
This has the effect that if the power factor is set at a low value e.g. 0-5, then
the reel will haul in slowly and elastically when there is some weight on the
line but hauls in fast and powerfully if there is not. If the power factor is set
at a value of 10, then the reel will use full power at all speeds.
STEPS
This parameter tells the reel how many steps to take in step jigging. Default
is 5 (the same value as the “step jigging” fishing system sets it to).
SEARCH SPAN
This parameter tells the reel at what depth the top of the search span is. The
surface is at zero and the bottom is at a value of 99. A value of 30 means
that the reel should start searching at the bottom and stop when 1/3 of the
distance from bottom up to the surface is left.
If one of the search systems is activated you can see how this number
changes accordingly.
SEARCH COUNT
This is the number of times the reel jigs at each depth before it hauls in the
line one jig length and starts jigging again. All the search systems set this
parameter at a value of ten.
STOP AT ZERO
If not in zero position, this parameter tells the reel to stop as soon as the
depth counter reaches zero when hauling in the line. If the value is zero the
reel hauls the line until the stop ring reaches the pulley.
RESET
If you are in trouble and have lost your way in all the parameters you can
reset (set the reel to the factory setting) the reel by activating the RESET
function.
SLACK SENSOR OPERATION
The slack sensor arm is the only part of the reel that needs constant
maintenance. To make this job as easy as possible information about it is
displayed on screen three.
