C-6000i Computerized Jigging Reel User Manual
31
The icon for it can be found in the lower left corner of the display. On the
left side of it two values are shown, which indicate the reading from the slack
sensor (SL) and the current consumption of the reel ( I(A) ).
The reading from the slack sensor should be checked once in a while. This is
done by watching the reading when there is no weight on the line (the slack
sensor arm is all the way up) and when there is no slack on the line (the line
pulls the slack sensor arm down). The reading should be 0 and 43-48
respectively.
If the reading is not correct then the slack sensor arm must be reconfigured
on screen five (see the sections SLACK SENSOR UP and SLACK SENSOR
DOWN on page 34).
SCREEN FOUR - Jigging Types
On this page the user can change the type of jigging (no parameters are
changed) e.g. the pollack fishing system uses the DNG JIG but the user may
want to use the pollack system with step jig. Then he first activates the
pollack system and then moves to screen four and selects the step jig.
On this screen the user can also “record” his own jig i.e. he can turn the
drum and the reel records his movements. He can then use it (playback) in
his own fishing systems or e.g. instead of DNG JIG in the pollack system.
The desired type of jigging can be selected by moving the cursor to the icon
for the jig and pressing the PLUS pad.
DNG JIG
The standard jigging action, going up and down. Sensing fish when moving
upwards (hauling).
STEP JIG
Instead of going up and down, the line is pulled up a fixed number of times
(see the parameter STEPS on page 30). Between each haul, the reel stops
for a period of one WAITING TIME (see the parameter WAITING TIME
on page 18).
SPEED CONTROLLED DOWNWARD JIG
If set at zero (default), the reel will pay out the line as fast as possible when
jigging downwards. If set at the value of one, the reel will control the speed
of the downward jig and try to maintain the speed as set by the parameter
DOWNJIG SPEED.
DOWNJIG SPEED
This parameter controls the speed of the downward jig, if the speed
controlled downward jig is active. The default value is 8 and each step
equals 10 RPM. The default is then 80 RPM.
