C-6000i Computerized Jigging Reel User Manual
33
your movements. When you are ready, push the MINUS pad and the reel
will release control of the drum, which can then be turned freely. Now the
reel has started to record your movements. You can record simultaneously
for a maximum of 80 seconds.
When you are finished push the MINUS pad once again. Now your jig has
been stored and the reel takes control of the drum.
One big difference is between the standard jig types and recorded ones. This
is that fish can be detected even though the drum is not moving.
Note! The reel starts to record when you push the minus pad and stops
recording when you push it again no matter if you move the drum or not.
SCREEN FIVE - Maintenance
This screen cannot be entered if the reel is not in stop position. On this
screen some maintenance parameters can be adjusted such as the signal from
the slack sensor and maximum speed when paying out. In later versions the
parameters for length and type of line used will be kept here.
At the bottom of the screen is this icon and on its right side are numbers in
two rows. This is for information only and is used when configuring the
slack sensor. The figure in the first row is the value of the signal from the
slack sensor. The value of this signal is usually in the range of 90 to 160.
The figure in the second row is the current consumption in amperes
multiplied by ten.
SLACK SENSOR UP
This parameter is used to tell the reel the value of the slack sensor signal
when there is a full slack on the line (slack sensor arm not pulled down by
the line). When the slack sensor arm is pulled up against the motor housing
by the spring, the value of the slack sensor signal is read from the screen.
The value of the parameter is set at the same value.
Note: Only the two last digits of the value for this parameter are shown
below the icon. Hence, if the value is increased from 90 to 110, then the
value below the icon will change from 90 to 99, then it changes to zero
and then it will change from 0 to 10.
If the value below the icon is 99 and it cannot be increased any more then
the value of the parameter is 199. On the other hand if the value below
the icon is 0 and cannot be decreased then the value of the parameter is 0.
If the value below the icon can be decreased from 0 to 99 or increased
form 99 to 0 then you are changing the value of the parameter from 99 to
100 and vice versa.
