DNT IPdio Tune - View of the Appliance

- 31 -
English
View of the Appliance
View of the Appliance
Front
WiFi antenna RJ45 Ethernet connector
digital output
analog output
FM antenna socket
USB Connector
DC power input
power on/off
Rear side
earphone jack remote sensor Play/Pause Back Tune/Select
Standby
Standby-LED Display Mode
SD card slot
