English
- 18 -
Specifi cation
Camera and wireless transmission box
Imaging Sensor CMOS
Total Pixels 640x480 Pixel
Modulation Mode FM
Bandwidth 18MHz
Transmission Frequency 2468 MHz (channel 4)
View Angle 110°
Transmission Power 6mW
Minimum Illumination 0,5Lux
IR Night Range 4m
Power Supply Supplied By Transmission Box
Consumption Current (Max.) 140mA
Dimensions (WxDxH) 528 x 137 x 40 mm
Weight (about) 252g
Monitor
LCD Screen Type color TFT (8,89mm (3.5”)
Effective Pixels 320x240 Pixel
Video System PAL/NTSC
Received Sensitivity ≤ -85dBm
Power Supply Voltage 12V
Consumption Current (Max.) 250mA
Unobstructed Effective Range(Min.) 50m
Dimensions (W x D x H) 108 x 37 x 75 mm
Weight (About) 165g
Operating Temperature -10 - +50°C
Operating Humidity (Max.) 85%RH max.
