REAR PANEL FUNCTIONS
The rear panel connections and function of the SR 460 are as follows:
1. AC POWER INPUT - AC power cord is inserted.
2. LEFT INPUT - This is the Left side input on the rear of the unit.
3. RIGHT INPUT - This is the Right side input on the rear of the unit.
4. STEREO INPUT - This is the Stereo input of the SR 460.
B
BLOCK AUDIO DIAGRAM
The following is a Block audio diagram of the SR 460:
M
MAINTENANCE AND SERVICE
Other than keeping the unit clean and occasionally checking the connectors and cables to the unit for integri-
ty, there is no maintenance necessary for the DOD Amplifier.
There are NO user serviceable parts inside the unit. Opening the chassis will void the warranty. All service and
repair must be performed by the factory for the warranty to remain in service.
1
2
3
4
Stereo
In/Out
Stereo
In/Out
Left
Balanced
Input
pre-amp
Time
Variable
Gain
Master
Level
Buffer
Individual
Control
Adphase
Driver
Right
Output
X 6
