POWER DISTRIBUTION CENTER (FUSE/RELAY)
Your vehicle is equipped with two electrical power
distribution centers located next to each other in the left
side of the engine compartment.
The power distribution centers house new plug-in
“Maxi” fuses which replace all the in-line fusible links
previously used. The power distribution centers also
contain “Mini”fuses and plug-in “ISO” relays. A label
inside the latching cover of the Power Distribution Cen-
ters identifies each component for ease of replacement, if
necessary. These fuses and relays can be obtained from
your dealer.
FUSE BLOCK
CAUTION!
When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If a
properly rated fuse continues to blow, it suggests a
problem in the circuit that must be corrected.
NOTE: If you are leaving your vehicle dormant for
longer than 21 days you may want to take steps to protect
your battery. You may do this by disconnecting the
battery or by disconnecting the two ignition-off draw
(I.O.D.) fuses located in the Auxiliary Power Distribution
Center (PDC) located in the engine compartment. The
I.O.D. cavities include a snap-in retainer that allows the
MAINTAINING YOUR VEHICLE 341
7
