Engine/Transmission Frontal Area Max. GTW (Gross Trailer
Wt.)
Max. Tongue Wt.
5.7L Automatic with
trailer tow package
40 SQ. FT. (3.72 square
meters)
Up to 2 persons & Lug-
gage 3,800 lbs (1724 kg)
380 lbs (172 kg)
40 SQ. FT. (3.72 square
meters)
Up to 3 persons & Lug-
gage 3,000 lbs (1361 kg)
300 lbs (136 kg)
40 SQ. FT. (3.72 square
meters)
Up to 4 persons & Lug-
gage 1,500 lbs (680 kg)
150 lbs (68 kg)
40 SQ. FT. (3.72 square
meters)
Up to 5 persons & NO
Luggage 1,000 lbs (454 kg)
100 lbs (45 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE:
The trailer tongue weight must be considered as
part of the combined weight of occupants and cargo, and
should never exceed the weight referenced on the Tire
and Loading Information placard. Refer to the Tire–
Safety Information Section in this manual.
258 STARTING AND OPERATING
