CAUTION!
•
When installing the Power Distribution Center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.
•
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.
Rear Power Distribution Center Fuses
Cavity Fuse Circuits
1 60 Amp
Yellow
Ignition Off Draw (IOD)
2 40 Amp
Green
Battery
3 ——
4 40 Amp
Green
Battery
5 30 Amp
Pink
Heated Seats - if equipped
6 20 Amp
Yellow
Fuel Pump
7 ——
8 15 Amp
Blue
Ignition Switch/Occupant Classi-
fication Module (OCM)
9 20 Amp
Yellow
Console Power Outlet
10 ——
