Cavity Fuse Circuits
30 10 Amp
Red
Door Modules/Power Mirrors -
if equipped/Steering Control
Module
31 ——
32 ——
33 ——
34 ——
35 5 Amp
Orange
Amplifier - if equipped/
Antenna/Ignition Delay/
Overhead Console - if equipped/
Passenger Door Lock & Express
Power Window Switch - if
equipped/Power Mirrors - if
equipped/Rear Defrost
36 20 Amp
Yellow
Hands Free Phone - if equipped/
Media System Monitor DVD - if
equipped/Radio/Satellite Re-
ceiver - if equipped
37 15 Amp
Blue
Transmission - NAG1
38 5 Amp
Orange
Analog Clock/Overhead Console
- if equipped
Cavity Fuse Circuits
39 10 Amp
Red
Heated Mirrors - if equipped
40 5 Amp
Orange
Heated Seats - if equipped/
Inside Rearview Mirror/Manual
Temperature Control (early
build) - if equipped
41 10 Amp
Red
AC Heater Control (except early
build MTC)/Tire Pressure Moni-
toring - if equipped
42 30 Amp
Pink
Front Blower Motor
43 30 Amp
Pink
Amplifier - if equipped/
Antenna/Rear Defrost
44 20 Amp
Blue
Amplifier - if equipped/Front
Control Module (FCM)/Sunroof -
if equipped
324 MAINTAINING YOUR VEHICLE
