FUSES/TIPM
Cavity
Cartridge
Fuse
Mini
Fuse
Description
J21 20 Amp
Yellow
— Front/Rear Washer
J22 25 Amp
Natural
— Sunroof Module
M1 — 15 Amp
Blue
Center High Mounted
Stop Light (CHMSL)/
Brake Switch
M2 — 20 Amp
Yellow
Trailer Lighting
M3 — 20 Amp
Yellow
—
M4 — 10 Amp
Red
Trailer Tow
M5 — 25 Amp
Natural
Inverter
M6 — 20 Amp
Yellow
—
FUSES/TIPM
Cavity
Cartridge
Fuse
Mini
Fuse
Description
M7 — 20 Amp
Yellow
Power Outlet #2 (BATT/
ACC SELECT)
M8 — 20 Amp
Yellow
Front Heated Seat (If
Equipped)
M9 — 20 Amp
Yellow
Rear Heated Seat (If
Equipped)
M10 — 20 Amp
Yellow
Ignition Off Draw — Ve-
hicle Entertainment Sys-
tem (IOD-VES), Satellite
Digital Audio Receiver
(SDARS), DVD, Hands-
Free Module (HFM),
Universal Garage Door
Opener (UGDO), Vanity
Lamp (VANITY LP)
M11 — 10 Amp
Red
(Ignition Off Draw) IOD-
HVAC/ATC, MW
SENSR, Underhood
Lamp (UH LMP)
