Dodge Avenger 2011 - Page 426

Cavity
Cartridge
Fuse
Mini Fuse Description
9
40 Amp
Green
—
Battery Feed –
Power Seats – If
Equipped/PZEV
Air Pump – If
Equipped
10 —
20 Amp
Yellow
Instrument Panel/
Power Locks/
Interior Lights
11 —
15 Amp
Lt Blue
Selectable Power
Outlet (Inside Cen-
ter Arm Rest)
12 —
20 Amp
Yellow
—
13 —
20 Amp
Yellow
Ignition
14 —
10 Amp
Red
Instrument Panel
Cavity
Cartridge
Fuse
Mini Fuse Description
15
40 Amp
Green
— Radiator Fan Relay
16 —
15 Amp
Lt. Blue
Cigar Lighter/
Sunroof – If
Equipped
17 —
10 Amp
Red
Wireless Control
Module (WCM)/
Clock/Steering
Control Module
(SCM)
18
40 Amp
Green
—
Auto Shutdown
(ASD) Relay
19 —
20 Amp
Yellow
Audio Amplifier –
If Equipped
20 —
15 Amp
Lt. Blue
Radio
424 MAINTAINING YOUR VEHICLE
