Dodge Avenger - Page 456

Cavity
Cartridge
Fuse
Mini Fuse Description
3—
10 Amp
Red
Center High
Mounted Stop
Light (CHMSL)/
Brake Switch
4—
10 Amp
Red
Ignition Switch
5—
20 Amp
Yellow
Trailer Tow – If
Equipped
6—
10 Amp
Red
Power Mirror
Switch/Climate
Controls
7—
30 Amp
Green
Ignition Off Draw
(IOD) Sense 1
8—
30 Amp
Green
Ignition Off Draw
(IOD) Sense 2
Cavity
Cartridge
Fuse
Mini Fuse Description
9
40 Amp
Green
Battery Feed –
Power Seats – If
Equipped
10 —
20 Amp
Yellow
Instrument Panel/
Power Locks/
Interior Lights
11 —
15 Amp
Lt Blue
Selectable Power
Outlet (Inside Cen-
ter Arm Rest)
12 — — —
13 —
20 Amp
Yellow
Ignition/Cigar
Lighter
14 —
10 Amp
Red
Instrument Panel
15
40 Amp
Green
— Radiator Fan Relay
454 MAINTAINING YOUR VEHICLE
