Dodge Caliber - Page 425

Cavity Cartridge
Fuse
Mini-
Fuse
Description
3 10 Amp
Red
CHMSL Brake Switch
Feed
4 10 Amp
Red
Ignition Switch Feed/
OCM
5 20 Amp
Yellow
Trailer Tow – If
Equipped
6 10 Amp
Red
IOD Sw/Pwr Mir/
Steering Cntrl Sdar/
Hands-Free Phone –
If Equipped
7 30 Amp
Green
IOD Sense1
8 30 Amp
Green
IOD Sense2
9 40 Amp
Green
Power Seats – If
Equipped
Cavity Cartridge
Fuse
Mini-
Fuse
Description
10 20 Amp
Yellow
CCN Power Locks/
Interior Lighting
11 15 Amp
Lt Blue
Power Outlet
12 20 Amp
Yellow
Ign Run/Acc Inverter
13 20 Amp
Yellow
Pwr Run/Acc Outlet
RR/Dome Lamp/
Cigar Lighter
14 10 Amp
Red
IOD CCN
15 40 Amp
Green
RAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt Blue
IGN Run/Acc Dome
Lamp/Sunroof/Rear
Wiper Motor/ACC
Inverter
424 MAINTAINING YOUR VEHICLE
