Dodge CARAVAN 2009 - Page 474

FUSES/TIPM
Cavity
Cartridge
Fuse
Mini-
Fuse
Description
M21 — 20 Amp
Yellow
Auto Shut Down
(ASD #3)
M22 — 10 Amp
Red
Right Horn (RT
HORN (HI/LOW)
M23 — 10 Amp
Red
Left Horn (LT HORN
(HI/LOW)
M24 — 25 Amp
Natural
Rear Wiper (REAR
WIPER)
M25 — 20 Amp
Yellow
Fuel Pump (FUEL
PUMP), Diesel Lift
Pump (DSL LIFT
PUMP) — Export
Only
M26 — 10 Amp
Red
Power Mirror Switch
(PWR MIRR SW),
Driver Window
Switch (DRVR WIND
SW)
FUSES/TIPM
Cavity
Cartridge
Fuse
Mini-
Fuse
Description
M27 — 10 Amp
Red
Ignition Switch (IGN
SW), Window Module
(WIN MOD)
M28 — 10 Amp
Red
Next Generation Con-
troller (NGC), Trans-
mission Feed (TRANS
FEED), J1962
M29 — 10 Amp
Red
Occupant Classifica-
tion Module (OCM)
M30 — 15 Amp
Blue
Rear Wiper Module
(RR WIPER MOD),
Power Folding Mirror
(PWR FOLD MIR)
M31 — 20 Amp
Yellow
Back-Up Lamps (B/U
LAMPS)
M32 — 10 Amp
Red
Occupant Restraint
Controller (ORC), TT
EUROPE
472 MAINTAINING YOUR VEHICLE
