FUSES/TIPM
Cavity
Cartridge
Fuse
Mini-
Fuse
Description
M33 — 10 Amp
Red
Next Generation Con-
troller (NGC), Global
Powertrain Engine
Controller (GPEC)
M34 — 10 Amp
Red
Park Assist (PRK
ASST), Heater Venti-
lation, Air Condition-
ing Module (HVAC
MOD), Headlamp
Wash (HDLP WASH),
Compass (COMPAS)
M35 — 10 Amp
Red
Heated Mirrors
M36 — 20 Amp
Yellow
Power Outlet #3
(BATT)
FUSES/TIPM
Cavity
Cartridge
Fuse
Mini-
Fuse
Description
M37 — 10 Amp
Red
Anti-Lock Brake Sys-
tem (ABS), Electronic
Stability Program
(ESP), Stop Lamp
Switch (STP LP SW),
Fuel Pump Rly Hi
Control
M38 — 25 Amp
Natural
Lock/Unlock Motors
(LOCK/UNLOCK
MTRS)
The heated mirrors, lower instrument panel power outlet
and removable floor console, when in the front position
are fused with self-resetting fuses that are only service-
able by an authorized dealer. The power seats are fused
by a 30 Amp circuit breaker located under the driver’s
seat. The power windows are fused by a 25 Amp circuit
breaker located under the instrument panel near the
MAINTAINING YOUR VEHICLE 473
7
