CAUTION!
•
When installing the power distribution center
cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the power distribution
center and possibly result in an electrical system
failure.
•
When replacing a blown fuse, it is important to
use only a fuse having the correct amperage rating.
The use of a fuse with a rating other than indicated
may result in a dangerous electrical system over-
load. If a properly rated fuse continues to blow, it
indicates a problem in the circuit that must be
corrected.
Cavity Cartridge
Fuse
Mini-
Fuse
Description
1 60 Amp
Yellow
— Ignition Off Draw
(IOD) Cavity 1 of the
Rear Power Distribu-
tion Center contains a
black IOD fuse needed
for vehicle processing
during assembly. The
service replacement
part is a 60 Amp yel-
low cartridge fuse.
2 40 Amp
Green
— Integrated Power Mod-
ule (IPM)
3— ——
4 40 Amp
Green
— Integrated Power Mod-
ule (IPM)
5 30 Amp
Pink
— Heated Seats – If
Equipped
422 MAINTAINING YOUR VEHICLE
