Dodge Challenger 2011 - Page 425

Cavity Cartridge
Fuse
Mini-
Fuse
Description
6 — 20 Amp
Yellow
Fuel Pump
7 — 15 Amp
Blue
Audio Amplifier – If
Equipped
8 — 15 Amp
Blue
Diagnostic Link Con-
nector (DLC)/Wireless
Control Module
(WCM)/Wireless Igni-
tion Node (WIN)
9 — 20 Amp
Yellow
Power Outlet
10 — 25 Amp
Natural
Vacuum Pump – If
Equipped
11 * ———
12 * ———
13 * ———
Cavity Cartridge
Fuse
Mini-
Fuse
Description
14 — 10 Amp
Red
AC Heater Control/
Cluster/Security Mod-
ule – If Equipped
15 — — —
16 — 20 Amp
Yellow
Heated Seat Module –
If Equipped
17 — 20 Amp
Yellow
Instrument Cluster
18 — 20 Amp
Yellow
Cigar Lighter (Instru-
ment Panel)
19 — 10 Amp
Red
Stop Lights
20 — — —
21 — — —
22 — — —
23 — — —
7
MAINTAINING YOUR VEHICLE 423
