Cavity Cartridge Fuse Mini-Fuse Description
19 — — Fuse — Spare
20 — — Fuse — Spare
21 30 Amp Pink (6.2L Super-
charged)
25 Amp Clear (LD STD)
— Fuel Pump (6.2L Super-
charged)
Fuel Pump (LD STD)
22 — 20 Amp Yellow – Police
10 Amp Red – LA
Right Spot Lamp – Police
Integrated Center Stack –
LA
23 — 10 Amp Red Fuel Door/Diagnostic
Port
24 — 15 Amp Blue Integrated Center Stack –
LD/LX
25 — 10 Amp Red Tire Pressure Monitor
538 MAINTAINING YOUR VEHICLE
