Cavity Cartridge Fuse Mini-Fuse Description
26 — 15 Amp Blue – LD/LX
25 Amp Clear – LA
30 Amp Green – LA 6.2L
Supercharged
Transmission / Electronic
Shift Module (LD/LX)
Fuel Pump (LA)
Fuel Pump (LA 6.2L Su-
percharged)
27 — 25 Amp Clear Amplifier – If Equipped
31 — 25 Amp Breaker Power Seats
32 — 15 Amp Blue HVAC Module/Cluster
33 — 15 Amp Blue Ignition Switch/RF hub
Module/Steering Column
Lock-LX If Equipped
34 — 10 Amp Red Steering Column
Module/Clock/Spare –
Police
35 — 5 Amp Tan Battery Sensor
7
MAINTAINING YOUR VEHICLE 539
