CAUTION! (Continued)
allow water to get into the power distribution
center and possibly result in an electrical system
failure.
• When replacing a blown fuse, it is important to use
only a fuse having the correct amperage rating. The
(Continued)
CAUTION! (Continued)
use of a fuse with a rating other than indicated may
result in a dangerous electrical system overload. If
a properly rated fuse continues to blow, it indicates
a problem in the circuit that must be corrected.
Cavity Cartridge Fuse Mini-Fuse Description
1 – – Fuse – Spare
2 40 Amp Green – Radiator Fan #1 – (Non 6.2L Super-
charged)
3 50 Amp Red – Electric Power Steering #1 – If
Equipped / Radiator Fan (6.2L Super-
charged) – If Equipped
4 30 Amp Pink – Starter
5 40 Amp Green – Electronic Stability Control
554 MAINTAINING YOUR VEHICLE
