When information mode is active, the current mode
setting for both audio channels is displayed. In addition
to the items called out by number, the remaining infor-
mation displays the current status of the source (such as
station frequency, name, preset or track number, song
title, artist name, album name, etc.).
1. Channel 1 Mode – Displays the current source for
Channel 1.
2. Channel 1 Shared Status – When the icon is displayed,
the audio for Channel 1 is also shared with the radio
and playing through the cabin speakers.
3. Channel 1 Audio Only/Mute - Audio: The audio only
icon is not used on Channel 1, in a single screen
system. Mute: when the Mute icon is displayed, the
audio for Channel 1 has been muted using the remote
control’s MUTE button.
4. Channel 2 Mode – Displays the current source for
Channel 2.
5. Channel 2 Shared Status – When the icon is displayed,
the audio for Channel 2 is also shared with the radio
and playing through the cabin speakers.
6. Channel 2 Audio Only/Mute – Audio: Only in a single
screen system: The audio only icon is displayed on
Channel 2 when Channel 1 is in a video mode. Mute:
when the Mute icon is displayed, the audio for Chan-
nel 2 has been muted using the remote control’s
MUTE button.
7. Channel 1 ENTER Button Action – When the ENTER
button on the remote control is pressed with the
⬙INPUT FILE #⬙ button visible on the screen, the screen
shows a numeric entry keypad which allows you to
enter a specific track number on data discs and HDD
4
UNDERSTANDING YOUR INSTRUMENT PANEL 409
