Rear Automatic Temperature Control The rear ATC system has floor air outlets at the
rear right side of the 3rd Row seats and over-
head outlets at each outboard rear seating
position. The system provides heated air
through the floor outlets or cool, dehumidified air
through the headliner outlets.
The rear system temperature control buttons
are located on the headliner on the passenger
side of the vehicle.
Icon Description
Rear Mode Control
Select the desired air distribution mode using the Mode Control Knob. The rear airflow distribution mode can be adjusted so
air comes from the headliner outlets, and floor outlets.
Panel Mode
Headliner Mode
Air comes from the outlets in the headliner. Each of these outlets can be individually adjusted to direct the flow of air. Moving
the air vanes of the outlets to one side will shut off the airflow.
Rear Automatic Climate Controls
58
