Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
Engine/
Transmission
GCWR (Gross Com-
bined Wt. Rating)
Frontal Area
Max. GTW
(Gross Trailer Wt.)
Max. Tongue Wt.
2.4L/
Automatic
6,000 lbs (2 722 kg) 22 sq ft (2.0 sq m)
1,000 lbs (454 kg) which
includes up to 5 persons &
Luggage
100 lbs (45 kg)
3.6L/
Automatic
(without
Trailer Tow
Prep Package
7,300 lbs (3 311 kg) 32 sq ft (3.0 sq m)
2,000 lbs (907 kg) which in-
cludes 1 to 2 persons & Luggage
200 lbs (91 kg)
7,300 lbs (3 311 kg) 32 sq ft (3.0 sq m)
1,500 lbs (680 kg) which in-
cludes 3 to 4 persons & Luggage
150 lbs (68 kg)
7,300 lbs (3 311 kg) 32 sq ft (3.0 sq m)
1,000 lbs (454 kg) which in-
cludes 5 to 7 persons & Luggage
100 lbs (45 kg) *
Except for AWD
models.
