Gehäuse mit montierter Busplatine, Netzteil und
(optionaler) Steckverbindung
case with assembled bus board, power supply board
and (optional) connector
Detailansicht von hinten
(mit XLR-Steckverbindung)
detail: rear view
(incl. XLR connector)
Obere Abdeckung (mit zusätzlichen Holzleisten) top cover (with additional wood strips)
Komplett montiertes Gehäuse
(Ansicht von oben)
completely assembled case
(top view)
Komplett montiertes Gehäuse
(Ansicht von vorne)
completely assembled case
(front view)
