8. Module Overview System A - 100
doepfer
22
Module Width Curr. Curr.@5V Description
A-107
26 200 -
Multitype Morphing Filter
voltage controlled multitype filter with 36 different filter types and morphing feature
A-108
12 40 -
6/12/24/48 dB Low Pass / Band Pass
voltage controlled low pass (ladder type) with 4 different slopes and bandpass
A-109
20 40 -
Voltage Controlled Signal Processor
(module no longer available)
combination of 24 dB low pass, VCA and panning unit (CEM3379 based)
A-110-1
10 70 -
Standard VCO
voltage controlled Oscillator with 4 different waveforms, hard-sync input
A-110-2
8? -
Basic VCO
(still under development)
voltage controlled Oscillator with 3 waveforms, hard and soft-sync input, linear FM input
A-110-4
8? -
Thru Zero Quadrature VCO
(still under development)
pure sine/cosine VCO with linear Thru-Zero.FM feature
A-111-1
14 40 -
VCO (High End)
(module no longer available)
like A-110 but improved waveforms, linear FM input, soft-sync input
A-111-5
24 80 -
Synthesizer Voice
(module no longer available)
VCO + VCF + VCF + ADSR + two LFOs
A-112
10 50 -
SAMPLER
8 bit sampler and wavetable oscillator
A-113
26 30 100
Submarmonic Generator
Sound Generation unit as used in the so-called Trautonium (4 subharmonic oscillators)
A-114
440 -
Dual Ring Modulator
2 separate ring modulators
A-115
820 -
Audio Divider
frequency divider for audio signals (rectangle waveforms)
A-116
820 -
WP - VC Waveform Processor
module for dynamic waveform modification
A-117
820 -
DNG / 808 - Digital Noise / Random Clock / 808-Source
digital noise and clock generator, 808-like sound source
A-118
820 -
Noise / Random
analog noise generator with white and adjustable colored noise, random voltage
