DOEPFER A-147 User Manual

A-147
VCLFO
System A - 100
doepfer
2
2. Overview
Controls and indicators:
1
Frequ. : Manual frequency control
2 CV : Attenuator for the voltage at input "
3
LED
: Frequency indicator for the triangle
and sine waves at outputs
§
and/or
$
4
LED
: Frequency indicator for the square
wave at output
%
5
LED
: Frequency indicator for the sawtooth
wave at output
&
In- / Outputs:
!
Reset
: Reset input for syncing the VCLFO
"
CV : Control voltage input
§ : Triangle wave output socket
$ : Sine wave output socket
% : Square wave output socket
& : Sawtooth wave output socket
A-147
VCLFO
Frequ.
0
10
➊
➋
➌
➍
➎
➏
➂
➃
➄
➁
0
10
CV
Reset
CV
➀
Voltage Controlled LFO
