DEPTH ADJUSTMENT
Loosen the two screws with the attached key. The following adjustments are now possible:
• Depth adjustment
• Inwards rotation of arm support cup
• Angular setting of brake
Make the adjustments wanted. Tighten carefully
Maximum + adjustment.
The black end plugs should always be visible.
