Installing and connecting the refrigerator CD0050, CRD1050
14
If you put the refrigerator in a recess, you can fix it inside with suitable screws:
➤ Remove the blanking plugs (fig. 5 2, page 4).
➤ Push the refrigerator into the recess.
➤ Use suitable screws (fig. 5 1, page 4) to fix the refrigerator in place.
➤ Press the blanking plugs (fig. 5 2, page 4) into the openings.
7.2 Undo the lock
A
The refrigerator has a locking mechanism (fig. 6 1, page 4) which is also used to
protect it during transport. The following settings are possible:
•
Lock (turn wheel clockwise all the way): The drawer is locked and secured.
To open the drawer, lift the handle up and lift the drawer out.
•
Vent (turn wheel anti-clockwise all the way): The drawer is slightly open, but
fixed in position.
Use this position if you are not going to use the unit for a long time.
7.3 Connecting the refrigerator
Connect the refrigerator to DC power
The refrigerator can be operated with 12 Vg or with 24 Vg .
A
➤ Determine the required cross section of the cable in relation to the cable length
according to fig. 7, page 4.
Key for fig. 7, page 4
NOTICE!
Only adjust the locking mechanism when the drawer is open. The unit
will be damaged if this is adjusted when the drawer is closed.
NOTICE!
To avoid voltage drops and loss of performance, keep the cable as short
as possible and avoid joins.
For this reason avoid additional switches, plugs or multi-way adapters.
Co-ordinate axis Explanation Unit
l Cable length m
∅ Cable cross section mm²
